Mirror Aluminum Plate Sheet

Last Updated: 2023-09-05

We have two types of mirror aluminum plate sheet : 1085 and 1070.

Features:

1. The use of their own mirror aluminum material, eliminating the polishing process, reduce the process and shorten the process. This material is mirror processing mechanical polishing surface generation, no coating, sandblasting, anode processing, without annealing anode or plating film, can be directly sandblasting, anode processing, sand particle size up to 320 or more rough.

2. Hardness: hardness uniformity, suitable for complex stamping forming, bending, stretching, integer is not easy to break.

3. Surface treatment: pure material, suitable for high requirements of the stability of the anodic oxidation surface treatment, such as chemical polishing, atomization, fog, two-color two anode, sandblasting, chemical sand, dyeing, sealing and other processing.


Application:

The product is suitable for signs, nameplate, computer chassis, household appliances, mobile phone, digital camera, MP3/MP4, notebook computer, video machines, mobile hard disk, CD player, audio panels, calculator, household electronic products requiring high shell or IT. The material is suitable for complex stamping, stretching, bending, drawing, anodizing, etc.. Suitable for high quality, high demand customers.

Packing:
wooden pallet packing, surface with PE film protection, film thickness 50+/-5um, the film quality time is 5 month, aluminum storage sites require dry, ventilated, avoid high temperature and direct sunlight. If the aluminum stored in high temperature or direct sunlight will cause the protection film can not tear off the phenomenon.


(1)    1070 Aluminium Bright Mirror Sheet Coil
1070 H24, H18
Thickness: 0.3--1.0mm
Width: 250mm--1500mm
Surface: Bright finish

Data sheet
Total reflection 86% Diffuse reflection ≤12%
Specular reflectivity 80%
Tension strength 125N/mm
Yield strength 105N/mm2
Rainbow degree 2
Elongation 2




(2)    1085 Aluminium Bright Mirror Sheet Coil
1085 H24, H18
Thickness: 0.3--1.0mm
Width: 250mm--1500mm
Surface: Bright finish

Aluminium - Technical Data
Product Type Total Reflectance Specular
Reflectance
Diffuse Reflectance
DIN 5036-3
Iridescence
Scale 1-4
Alloy
Purity
Temper
(hardness)
Min Tensile Strength
Mpa
Min Vield Strength
Mpa
Minimum
Elongation
A5A10
ASTM
E 1651
DIN
5036-3
60° long 60° trans
1085 specular
standard
86 86 80 77 15 1 Al 99,85 H18 125 105 2

Mirror Aluminum Plate Sheet is widely used for Lighting, Decoration, Architecture, Consumer Electronics.


(1)Lighting Mirror Aluminium Sheet

Nowadays aluminum is a very fashionable metal, widely used in every field. Due to its advantages of corrosion resistance, mechanical strength and excellent plasticity, aluminum is suitable to be used in various mechanical processing. In addition, its excellent light reflection properties and surface processing technology make aluminum applicable to all types of lighting equipment.
Signi Aluminium always focuses on bringing anodized aluminum used in lighting technology field. In the past years, we've been accumulating a lot of experience in lighting.
The main application scopes of products used in lighting include:
•    Outdoor lamps
•    Lattice lights
•    LED lamps and lanterns
•    Tri-proof lights
•    Tunnel lights
